JVN Build Tip: CIM Pinions

The CIM motor has 0.75" diameter protrusion on its face which is GREAT for piloting (keeping the CIM centered where you want). Relying on the (2x) 10-32 mounting screws will work, but won't result in as consistent a mounting. If you have any slop in your mounting holes the CIM could shift, resulting in a loose or tight gear mesh.

Typically, people use a 12-tooth or 14-tooth 20DP gear as a CIM pinion (see KOP transmissions).

One of my favorite tricks? Always opt for the 12t pinion. The 12t gear fits through a 0.75" hole while the 14t gear does not. This allows you to swap a CIM motor in/out without removing the pinion gear. You can have CIM motors on-hand ready to swap in.

Then again... I've never had to remove a CIM motor except to work on something else... Maybe this isn't such an expert tip after-all.

As always... good luck in 2011!

-John

Originally posted here: http://jvengineering.blogspot.com/20...m-pinions.html
__________________
In the interest of full disclosure: I work for VEX Robotics a subsidiary of Innovation First International (IFI).
Reply With Quote
  #2   Spotlight this post!
Unread 01-19-2011, 03:43 PM
sanddrag sanddrag is offline
back to school ;-)
FRC #0696 (Circuit Breakers)
Team Role: Teacher

Join Date: Jul 2002
Rookie Year: 2002
Location: Glendale, CA
Posts: 7,860
sanddrag has a reputation beyond reputesanddrag has a reputation beyond reputesanddrag has a reputation beyond reputesanddrag has a reputation beyond reputesanddrag has a reputation beyond reputesanddrag has a reputation beyond reputesanddrag has a reputation beyond reputesanddrag has a reputation beyond reputesanddrag has a reputation beyond reputesanddrag has a reputation beyond reputesanddrag has a reputation beyond repute
Re: JVN Build Tip: CIM Pinions

Another great tip John. I've had to remove far more than my fair share of CIM motors and it's a real pain every single time the pinion is not smaller than 0.75" OD. However, sometimes I don't like using 12 tooth 20DP gears because I believe they are undercut. Not a big deal really, but I just feel the 14 tooth gears mesh a bit nicer. I really wish we could get a bigger boss on the face of the CIM, like 1" maybe.

Also, for the pinions, which see the most cycles of operation, I like to use Martin S20XX series gears, as they're slightly harder and I've experienced some odd wear issues with the AndyMark pinions. Of course, if I wanted to I could probably harden the AndyMark ones.
__________________
Teacher/Engineer/Machinist - Team 696 Circuit Breakers, 2011 - Present
Mentor/Engineer/Machinist, Team 968 RAWC, 2007-2010
Technical Mentor, Team 696 Circuit Breakers, 2005-2007
Student Mechanical Leader and Driver, Team 696 Circuit Breakers, 2002-2004

Support Team 696 on DonorsChoose!

Last edited by sanddrag : 01-19-2011 at 03:45 PM.
Reply With Quote
  #3   Spotlight this post!
Unread 01-19-2011, 03:58 PM
Brandon Holley's Avatar
Brandon Holley Brandon Holley is offline
Chase perfection. Catch excellence.
AKA: Let's bring CD back to the way it used to be
FRC #0125 (NU-TRONs, Team #11 Alumni (GO MORT))
Team Role: Engineer

Join Date: Jan 2004
Rookie Year: 2001
Location: Boston, MA
Posts: 2,422
Brandon Holley has a reputation beyond reputeBrandon Holley has a reputation beyond reputeBrandon Holley has a reputation beyond reputeBrandon Holley has a reputation beyond reputeBrandon Holley has a reputation beyond reputeBrandon Holley has a reputation beyond reputeBrandon Holley has a reputation beyond reputeBrandon Holley has a reputation beyond reputeBrandon Holley has a reputation beyond reputeBrandon Holley has a reputation beyond reputeBrandon Holley has a reputation beyond repute
Send a message via AIM to Brandon Holley
Re: JVN Build Tip: CIM Pinions

Totally agree about the 12tooth pinion! Even for the one time you assemble it, it is worth it to just pass the entire motor through the 0.75" hole and tighten it in place.

I can't recall a time where I've switched out just a CIM motor, but I can imagine getting to that step and having to take the pinion off would be a pain!

-Brando
__________________
MORT (Team 11) '01-'05 :
-2005 New Jersey Regional Chairman's Award Winners
-2013 MORT Hall of Fame Inductee

NUTRONs (Team 125) '05-???
2007 Boston Regional Winners
2008 & 2009 Boston Regional Driving Tomorrow's Technology Award
2010 Boston Regional Creativity Award
2011 Bayou Regional Finalists, Innovation in Control Award, Boston Regional Finalists, Industrial Design Award
2012 New York City Regional Winners, Boston Regional Finalists, IRI Mentor of the Year
2013 Orlando Regional Finalists, Industrial Design Award, Boston Regional Winners, Pine Tree Regional Finalists
2014 Rhode Island District Winners, Excellence in Engineering Award, Northeastern University District Winners, Undefeated 18-0, Industrial Design Award, Pine Tree District Chairman's Award, Pine Tree District Winners
Reply With Quote
  #4   Spotlight this post!
Unread 01-19-2011, 04:37 PM
Teched3 Teched3 is offline
Hodge1
FRC #0175 (BuzzRobotics)
Team Role: Mentor

Join Date: Apr 2006
Rookie Year: 1996
Location: Connecticut
Posts: 313
Teched3 has much to be proud ofTeched3 has much to be proud ofTeched3 has much to be proud ofTeched3 has much to be proud ofTeched3 has much to be proud ofTeched3 has much to be proud ofTeched3 has much to be proud ofTeched3 has much to be proud ofTeched3 has much to be proud of
Smile Re: JVN Build Tip: CIM Pinions

As an alternative to using a smaller pinion than you want, you can make an adapter bushing for the CIM 3/4 boss and make a larger centering hole to accommodate the larger pinion. Of course, you are limited to a max diameter on the bushing by the edge to edge distance between the 10-32 FH screws to mount the CIM. In addition, you should have several CIM/Bushing motors set up so you are not "pressed" to remove a pinion if a swap becomes necessary. By the way, we have never lost a CIM motor, and have done a review of them in the past after a long competition season and post season play, and have never been disappointed in their durability.
__________________
Sweat the details
Why is there never enough time to do it right, but always enough time to do it again!
Even if you're on the right track, if you sit still, you'll get run over!!!
Reply With Quote
  #5   Spotlight this post!
Unread 01-19-2011, 04:42 PM
Unsung FIRST Hero
JVN JVN is offline
VEX Robotics Engineer
AKA: John Vielkind-Neun
FRC #0148 (Robowranglers)
Team Role: Engineer

Join Date: May 2001
Rookie Year: 2000
Location: Greenville, Tx
Posts: 3,107
JVN has a reputation beyond reputeJVN has a reputation beyond reputeJVN has a reputation beyond reputeJVN has a reputation beyond reputeJVN has a reputation beyond reputeJVN has a reputation beyond reputeJVN has a reputation beyond reputeJVN has a reputation beyond reputeJVN has a reputation beyond reputeJVN has a reputation beyond reputeJVN has a reputation beyond repute
Re: JVN Build Tip: CIM Pinions

Quote:
Originally Posted by JVN View Post
As always... good luck in 2011!

-John

Originally posted here: http://jvengineering.blogspot.com/20...m-pinions.html
Another tip I've been asked to pass along: CIM motors aren't designed to handle significant cantilevered load -- make sure you're not using them in an application where they have significant side load on the shaft.

Luckily, most people don't really do this so it usually isn't an issue.
__________________
In the interest of full disclosure: I work for VEX Robotics a subsidiary of Innovation First International (IFI).
Reply With Quote
  #6   Spotlight this post!
Unread 01-22-2011, 10:07 AM
colin340 colin340 is offline
team person man
AKA: Colin Nobles
FRC #0340 (G.R.R)
Team Role: Leadership

Join Date: May 2005
Rookie Year: 2005
Location: rochester
Posts: 422
colin340 has a reputation beyond reputecolin340 has a reputation beyond reputecolin340 has a reputation beyond reputecolin340 has a reputation beyond reputecolin340 has a reputation beyond reputecolin340 has a reputation beyond reputecolin340 has a reputation beyond reputecolin340 has a reputation beyond reputecolin340 has a reputation beyond reputecolin340 has a reputation beyond reputecolin340 has a reputation beyond repute
Send a message via AIM to colin340
Re: JVN Build Tip: CIM Pinions

Quote:
Originally Posted by sanddrag View Post
Another great tip John. I've had to remove far more than my fair share of CIM motors and it's a real pain every single time the pinion is not smaller than 0.75" OD. However, sometimes I don't like using 12 tooth 20DP gears because I believe they are undercut. Not a big deal really, but I just feel the 14 tooth gears mesh a bit nicer. I really wish we could get a bigger boss on the face of the CIM, like 1" maybe.

Also, for the pinions, which see the most cycles of operation, I like to use Martin S20XX series gears, as they're slightly harder and I've experienced some odd wear issues with the AndyMark pinions. Of course, if I wanted to I could probably harden the AndyMark ones.
Could i get a link to the gears you like to use
