scherbs17 04-02-2013 17:13

No auto-resetting fuses on Spikes?

I thought I remember reading in years past that the general recommendation was to replace the standard 20A automotive fuse on the Spikes with the auto-resetting fuses we use everywhere else. I don't remember this violating any of the rules, yet <R65> and the Q&A this year say differently... was I incorrect in past years? I don't remember this only applying to the compressor.

https://frc-qa.usfirst.org/Question/...-solenoids-etc

-Rob

Jon Stratis 04-02-2013 17:17

Re: No auto-resetting fuses on Spikes?

Yes, you were incorrect in past years. At least for the past 6 seasons I've been involved with, this same rule has been in place.

artdutra04 04-02-2013 17:24

Re: No auto-resetting fuses on Spikes?

The only allowed use of a 20-amp breaker instead of a fuse has been for the air compressor.

This rule has been the same since at least 2006, and is only in place because the inrush current of the compressor can occasionally surge over 20 amps for a brief moment causing them to trip.

apalrd 04-02-2013 23:17

Re: No auto-resetting fuses on Spikes?

R60 in 2010 allowed the breaker on any Spike. We used window motors on Spikes with breakers without issue.

R55 in 2011 banned it again.

This is another rule that really makes no sense. But, it is a rule.

EricVanWyk 04-02-2013 23:21

Re: No auto-resetting fuses on Spikes?

Quote:

Originally Posted by apalrd (Post 1227755)
This is another rule that really makes no sense. But, it is a rule.

The inrush current profile of a compressor is very different from that of a potentially stalled motor. The protection profile of a self reseting breaker is very different from that of a one time fuse. This isn't an arbitrary rule.

Retired Starman 04-02-2013 23:26

Re: No auto-resetting fuses on Spikes?

Quote:

Originally Posted by apalrd (Post 1227755)
R60 in 2010 allowed the breaker on any Spike. We used window motors on Spikes with breakers without issue.

R55 in 2011 banned it again.

This is another rule that really makes no sense. But, it is a rule.

Actually, it makes a lot of sense. If you put a motor on the Spike and it pulls too much current under load, the fuse will blow, end of story.

If you have a reset breaker in there, it will snap, reset, snap again, reset, over and over again, not providing proper circuit protection and causing something else more important to become the fuse, sometimes with frightening consequences.

The use of the resetting breaker in the compressor is a concession suggested by, I believe, the manufacturer of the compressor. It has a high in-rush current on startup, but a much lower running current. Other motors don't have that characteristic.

Dr. Bob
Chairman's Award is not about building the robot. Every team builds a robot.

apalrd 04-02-2013 23:44

Re: No auto-resetting fuses on Spikes?

To me, it's like saying you can't use a CIM on a Victor because the stall current of a CIM is greater than the current rating of the Victor. The Victor can handle significantly more current for quite a while, longer than it will take for the breaker to trip.

The stall current for all of the Spike-legal motors is below or very slightly above 20a anyway, so it's irrelevant since the Spike can supply stall current indefinitely. The resetting breaker gives me more peace of mind that a one-time fuse, in terms of vehicle reliability and maintenance.

fox46 05-02-2013 00:50

Re: No auto-resetting fuses on Spikes?

I have never understood why spikes have fuses. They are already current protected by the PD board with an auto resetting breaker. Furthermore, I have (outside of FIRST) used a spike to switch 40A+ with no issue. I personally like the idea of downgrading the auto resetter in the PD board to a 10A or 15A. At least this way the system will give you warning that a mechanism is drawing too much power with a temporary shut down rather than a "oh too bad, no more using that function for the rest of the match, better luck next time!" blown fuse.

Mark McLeod 05-02-2013 08:40

Re: No auto-resetting fuses on Spikes?

Quote:

Originally Posted by fox46 (Post 1227798)
I have never understood why spikes have fuses. They are already current protected by the PD board with an auto resetting breaker.

Stop me if you've heard this before...:)

The breakers are there and sized to protect the wiring from melting and bursting into flame, not the electrical components along that wiring.

Electrical components must protect themselves, as their circuit designers are the only ones who know what the design limitations are.
Wires are slow to burn components, but electronics are quick to fry components.
The Snap-Action circuit breakers we use are slow to respond components to match wiring characteristics of slow to burn.

kevin.li.rit 05-02-2013 09:05

Re: No auto-resetting fuses on Spikes?

Quote:

Originally Posted by apalrd (Post 1227777)
The stall current for all of the Spike-legal motors is below or very slightly above 20a anyway, so it's irrelevant since the Spike can supply stall current indefinitely. The resetting breaker gives me more peace of mind that a one-time fuse, in terms of vehicle reliability and maintenance.

That's not true of the RS775-12. Per the datasheet on the breakers, you'd very likely be able to run it at +20A for extended periods of time if not continuously. http://www.snapaction.net/pdf/vb3.pdf

apalrd 05-02-2013 12:09

Re: No auto-resetting fuses on Spikes?

Quote:

Originally Posted by Coffeeism (Post 1227896)
That's not true of the RS775-12. Per the datasheet on the breakers, you'd very likely be able to run it at +20A for extended periods of time if not continuously. http://www.snapaction.net/pdf/vb3.pdf

Stall for that motor is 30a (spec).

At stall, the breaker will trip between 3.9 and 47 seconds.

The motor will certainly not last 47 seconds at stall.

Spike specs: According to Vex Pro site
Quote:

-20a continuous
-100a surge for <2 seconds
-Design will accept 20a auto-resetting circuit breaker
100a is 500% over the rated current of 20a for 2s. The surge current rating of the Victor is only half that, 250% for the same time period. We frequently run motors rated for 200% rated stall current through the Victors without issue.


It's still like saying a Victor can't ever handle more than 60a (rated continuous current) so we can't connect a possibly larger load to it. The Spike will live with a 20a breaker and any Spike-legal motors. The 20a breaker will still trip if the wire shorts, which could already happen with a 20a breaker in a Spike for the pump.

fox46 05-02-2013 12:13

Re: No auto-resetting fuses on Spikes?

Quote:

Electrical components must protect themselves, as their circuit designers are the only ones who know what the design limitations are.
That's an excellent point but then how come we don't stick with the same logic that was used to design the spikes and see fuses on all electrical components? Albeit the jags have an over temperature shutdown but what of the Talons and Victors? The Victor manual specifically states:

Quote:

Ensure there is a circuit breaker either inline with
the 12V power input to the speed controller, or inline
with the motor. Use an appropriate circuit breaker for
your application to ensure that long term exposure to
a stalled motor (high currents) will not overheat the
Victor.

kevin.li.rit 05-02-2013 12:23

Re: No auto-resetting fuses on Spikes?

Quote:

Originally Posted by apalrd (Post 1228001)
Stall for that motor is 30a (spec).

At stall, the breaker will trip between 3.9 and 47 seconds.

The motor will certainly not last 47 seconds at stall.

Right, but the motor can operate between 20A-<30A, above the spikes continuous rating. Potentially up to 47 seconds with the snap action breaker.

apalrd 05-02-2013 12:35

Re: No auto-resetting fuses on Spikes?

Quote:

Originally Posted by Coffeeism (Post 1228009)
Right, but the motor can operate between 20A-<30A, above the spikes continuous rating. Potentially up to 47 seconds with the snap action breaker.

The Jaguar is rated as follows:
-40a continuous
-60a for up to 2s
-100a for up to 0.2s

At 60a, the 40a snap action MX5 will trip between 3.9 and 47 seconds.

According to the Jaguar's spec, it has exceeded its spec limit before the best-case breaker trip.

So maybe we shouldn't use Jaguars, because we can pull more current with a CIM than they are rated for before the breaker will trip?

The point is that, in our use-case, it is reasonable to exceed the continuous current ratings for a short period of time. The Spike also has the highest relative current rating of any FRC-legal controller.

Jon Stratis 05-02-2013 12:41

Re: No auto-resetting fuses on Spikes?

The inclusion of fuses on electrical components is a rather interesting topic. For the most part, fuses are used for safety. When examining the failure mode of a particular circuit, you need to consider the safety implications of such a failure. A few examples:

- Outdoor Christmas lights. Many of these have integrated fuses in them, as a failure in the circuit could start a fire on your lawn. This is doubly reinforced with a GFCI breaker on your outdoor outlets.
- In cars. There are numerous fuses in cars. These all are designed to protect the cabin from a fire caused by a short.

So, what about Spikes and speed controllers?

Well, with Spikes the failure mode can be pretty severe - the contacts inside a Spike are pretty large, and the plastic holding the whole thing together can melt. As a result, a Spike can short circuit, causing your breaker on the PDB to trip, or it could short the outputs to the inputs, causing the motor hooked up to it to be permanently on - a potentially much more dangerous situation, depending on what the motor is doing.

What about a speed controller? Well, speed controllers are much more complex. Generally speaking, failures in these end up with an open circuit - the motor simply won't work. This is a much safer failure mode.

Fuses can also be used to protect expensive equipment. For example, many surge protectors have fuses in them - the fuse will blow before your computer or TV is destroyed.
