Banebot 775/Planetary Gearbox Question


We are planning to mount a RS775 Motor with a P60 Gearbox to a plate using the holes that attach the gearbox to the motor.

http://banebots.com/docs/P60A-DATASHEET.pdf

Unfortunately (in the top view) this doesn't show us exactly how far the holes are from each other or from the edge of the gearbox.

Does anyone know these dimensions?

Thank You C:

Re: Banebot 775/Planetary Gearbox Question


I don't have one with me right now, but I asked someone to measure it and they told me the center to center distance between the holes is 1-3/16", the center of the hole to the edge of the face is 5/32", and the depth of the cutout around the bolt head is 5/32".

Re: Banebot 775/Planetary Gearbox Question


Thank you so much! You're the bestest.

Re: Banebot 775/Planetary Gearbox Question


These might be of some help for CAD purposes:

http://blogs.solidworks.com/teacher/...d-library.html

http://www.chiefdelphi.com/forums/sh...ad.php?t=95842

http://www.chiefdelphi.com/forums/sh...84#post1005984
