Code Orange 3476 2014 "Hanalei" Robot Reveal


Code Orange 3476 would like to present "Hanalei," our 2014 robot.

http://youtu.be/yy46UnLO20U

• 6 wheel WCD w/ shifters

• Fast reloading catapult

• Ground Intake

• 2 ball hot target detecting autonomous

• Easy inbounding into robot

Feel free to ask questions and see you at Las Vegas and Championship!

Re: Code Orange 3476 2014 "Hanalei" Robot Reveal


Can't wait to compete with you guys in Vegas!

Re: Code Orange 3476 2014 "Hanalei" Robot Reveal


Wait!? Is that a Hawaiian word you used to name your robot?

Cool.

Please do explain.

Re: Code Orange 3476 2014 "Hanalei" Robot Reveal


We name our robots after famous surf breaks: Pipeline (2012), Mavericks (2013) and now Hanalei (2014). Hanalei, Kauai, is a great place to surf with family and friends. In that way, it represents the spirit of cooperation that is essential to Aerial Assist.

Re: Code Orange 3476 2014 "Hanalei" Robot Reveal


What are you guys using to do the hot goal detection? Maybe I'm missing it, but I don't see a camera on the bot.

Re: Code Orange 3476 2014 "Hanalei" Robot Reveal


That's awesome!

Re: Code Orange 3476 2014 "Hanalei" Robot Reveal


Excited to compete with you guys at Las Vegas and Championships!

Re: Code Orange 3476 2014 "Hanalei" Robot Reveal


Good call, Thad House. You will find the sensor we use for hot target detection at http://www.alliedelec.com/search/pro...x?SKU=70167439

Re: Code Orange 3476 2014 "Hanalei" Robot Reveal


We really should trade sensors, our FIM one is orange and the your Banner one is black.

Hopefully we will be at your practice this week, we have some ideas to fix the timing issues with the goal.

Las Vegas is gonna be fun.

Re: Code Orange 3476 2014 "Hanalei" Robot Reveal


Mark, how about Saturday? We are having another scrimmage and would love for 3309 to join us.

Re: Code Orange 3476 2014 "Hanalei" Robot Reveal


Care explain your setup? What exactly are you detecting?

Re: Code Orange 3476 2014 "Hanalei" Robot Reveal


Its a retro-reflective sensor, it has a LED in it, and the sensor detects the light being reflected back. Its super easy to use, this one may be a bit different, but the IFM one I use just has to be tuned once. They even blinks at you when you turn on the robot so you can check the sensor during match setup. Shine it on the retro reflector and see it it reads hot.

The hot zone timing is another problem, I need a bigger delay in my auto. Not sure how I am going to make up that time.

Re: Code Orange 3476 2014 "Hanalei" Robot Reveal


Yes, the timing is a bit difficult to perfect.

Re: Code Orange 3476 2014 "Hanalei" Robot Reveal


Looks great CO. It appears that you have the ability to catch - has this been tested/planned?

Re: Code Orange 3476 2014 "Hanalei" Robot Reveal


We certainly do have the ability to catch. This was one of our major focus points when designing the fold-out rear wall in order to increase our catching area by 20" in each direction. We did originally have similar fold-out side walls that gave us a huge catching area (similar to 33), but we currently do not have them on the robot.

We haven't tested catching very much (due to the aggressive nature of Arial Assist the line-up is difficult) but we are definitely capable.

Re: Code Orange 3476 2014 "Hanalei" Robot Reveal


Have you seen the way 2056 catches? They line up against the field wall and all they have to do is backup or move forward to the correct distance.

Re: Code Orange 3476 2014 "Hanalei" Robot Reveal


Thanks, that looks like a good strategy.

Re: Code Orange 3476 2014 "Hanalei" Robot Reveal


That's a very nice design. Kauai is one of my favorite places to visit.

What is the purpose of the two 1" square tube arms that come up at 0:37, 0:38 and 1:13? Do they modify the ball trajectory or do they keep the ball in the proper location for the shooter arm? What is the purpose of the polycarbonate "hinges" in the middle of those arms?

What is the ball on at 0:14?

Thanks.

Re: Code Orange 3476 2014 "Hanalei" Robot Reveal


Thanks. The 1x1 extrusion arms are for both positioning the ball and choosing a trajectory. As for the hinges, they allow the ball to quickly roll over into the catapult while also allowing us to hold the ball securely in place for driving.

The thing at 0:14 is a LEGO robot built to carry the ball. It was just a joke.

Re: Code Orange 3476 2014 "Hanalei" Robot Reveal


We are also very excited to compete with you guys at the Las Vegas Regional.

Re: Code Orange 3476 2014 "Hanalei" Robot Reveal


Awesome bot!

Good luck everyone!

Re: Code Orange 3476 2014 "Hanalei" Robot Reveal


Re: Code Orange 3476 2014 "Hanalei" Robot Reveal


Thanks for the info.

Is this how you "condition" the balls to make them more spherical and shoot more consistently? Is there some secret technique that your human player (at 0:40) and 118's share?

https://plus.google.com/u/0/photos/113252386277699028908/albums/5994184008396962545/5994186996176699042?pid=5994186996176699042&oid=11 3252386277699028908

Re: Code Orange 3476 2014 "Hanalei" Robot Reveal


You figured out our secret! :p

Re: Code Orange 3476 2014 "Hanalei" Robot Reveal


Has any other Robot Shot in Autonomous for the High Goal, Missed, then Caught the Re-bounded Ball and Shot it to Score in the Hot High Goal? Here is a 6 second video from the San Diego Regional, Match #11, showing "Hanalei" doing just that: http://www.youtube.com/watch?v=ufF0g_Tj0ts :cool:
We are getting ready for the Las Vegas Regional, April 3 - 5, 2014.

Re: Code Orange 3476 2014 "Hanalei" Robot Reveal


Awesome! Looking forward to competing with you guys in Vegas!

Re: Code Orange 3476 2014 "Hanalei" Robot Reveal


Awesome job at the SD regional. I always tried to watch the matches you where in. Great build and good strategies!

Re: Code Orange 3476 2014 "Hanalei" Robot Reveal


Is this programmed to do this? just in case you get bounce back? If so that's pretty unique of your programmers to think that far ahead.

Re: Code Orange 3476 2014 "Hanalei" Robot Reveal


Answer42-
Hanalei is programmed to run an auto mode that just shoots the first ball in the goal and then drives forward with our intake on. We have limit switches in our catapult that detect whether a ball is in the catapult and we use these to wait to shoot until our next ball is in our catapult. This runs on a loop for the rest of auto so if any balls get near our intake or bounce back into our robot we can shoot them. This also prevents us from dry-firing our catapult too often or mis-firing if something else in the autonomous mode has delayed the ball from reaching the catapult in the normal amount of time. :)
