fembots692

23-01-2015 22:39

power D-link with the new distribution board???

Our electronics team is having problems connecting the D-link to the new power distribution board. How do we get power to the D-link?

MrForbes

23-01-2015 22:42

Re: power D-link with the new distribution board???

Did you see the wiring diagram?

https://wpilib.screenstepslive.com/s...control-system

Chris_Ely

23-01-2015 22:42

Re: power D-link with the new distribution board???

Connect it to the port on the VRM that says "Radio Power."

See this for details.

TFleig78

23-01-2015 22:42

Re: power D-link with the new distribution board???

Follow this guide:

https://wpilib.screenstepslive.com/s...control-system

Christopher149

23-01-2015 22:42

Re: power D-link with the new distribution board???

Quote:

Originally Posted by fembots692 (Post 1433092)

Our electronics team is having problems connecting the D-link to the new power distribution board. How do we get power to the D-link?

Follow this guide. Basically, the d-link is plugged into the Voltage Regulator Module, which in turn is plugged into one of the appropriate Weidmuller connectors on the Power Distribution Panel. (apparently triple ninja'd)

Sperkowsky

24-01-2015 18:05

The difference is there is a supplied voltage regulator module this year which makes it so you don't need to use your own voltage regulator as we had to in previous years.
