We need help... A lot of it


Hey guys Im Sam from 2869 and we have some major issues. We "finished" the elevator system today only to find there is a couple of fatal flaws.

Basically the wheel that is supposed to make the wire move slips and does not actually move the cable. Another issue is the elevator platform is so tight on bot that it barely moves unless you put a good amount of force into it.

Its too late now to do anything on the bot and yes we bagged and tagged it. So we have to work with the 30 pounds.

Another thing to consider is the bot already weighs 117 pounds.

We have the funds necessary (Just recieved sponsorship money) the real issue is having enough time. Our regional is on March 27th.

Another thing to consider is our lack of resources we have in our lab at our hands. We are working with bar stock L bracket and Lexan. We have no 8020 no alumium sqaure or rectangular tubing ect.

Heres the Sketchup model of what its supposed to look like

https://www.mediafire.com/?ld6imc778bz3iec

and here are some pics of the "finished" product.













Extra high quality pics for download (Much better pics)
https://www.mediafire.com/?odv4xv2bc...ooqrgwfrwb8f96
Thanks for your support and ideas hope your stop build day went better then ours. - Sam

Re: We need help... A lot of it


Out of curiosity why did you bag it now instead of much latter at night like 10?
The extra hours of bug fixing might have been nice.

Re: We need help... A lot of it


Is your wire/cable tied off through the wheel? OR is it just wrapped around?

Not sure how the system is failing from the pics.

Our mentor wanted to go home at 5:30

It's just wrapped around. The biggest problem area is the slipping wheel (the one connected to the motor at the bottem left and right.

Re: We need help... A lot of it


The elevator might be getting stuck due to the rails not being parallel to each other.

Re: We need help... A lot of it


How many wraps of cable do you have around your winch? I believe the recommended number is 2-3, looks like you don't have that many.

This would be a quick, light fix, involving a longer cable and whatever you use to attach the cable to the drum/terminate the cable. That's all you'd need. Depending on your setup, attaching the cable to the winch could work very well too.

It is because the elevator is too tight basically the easiest fix imo is to dremel out a slot on the bar stock and slide over the bearing blocks. The issue is we can't throw sparks in the competition and I am not sure if there is a machine shop. So we may have to drill out 4 more holes but it will be hard.

It's one continuous cable and they terminate connected to the elevator plate. There is only one cable but the way it's setup I don't know how you would use more then one cable.

I think I need to find more detailed pics that show the pulley system better. Because I think it's slightly confusing what we actually tried to do.

Re: We need help... A lot of it


You don't need to use more than one. You just bring in a longer piece of cable.

As follows:
1) Unterminate one end of existing cable.
2) Terminate one end of new, longer cable where previous cable used to be.
3) Run new cable and unrun old cable along the same path, until you hit the winch drum.
4) Wrap new cable around drum about 3 times.
5) Continue #3 above until you reach the other termination point.
6) Terminate new cable (probably want to do a temporary termination here, and make it permanent later). Make sure old cable is gone.
7) Test.

Re: We need help... A lot of it


Nope, I think I understand you. The cable is terminated to a moving plate on the elevator, on both ends, and the rest of it moves through associated pulleys to the drum, where it wraps around once and continues to the other termination point via more pulleys if needed. See my last post.

Re: We need help... A lot of it


the part where I am losing you is the drum. What do you mean by drum? Do you mean the small wheel connected to the motor.

I am starting to catch some sort of drift. will wrapping the cable around the moving wheel make it so theres tension to make it contact the wheel and actually move? Our imediate reaction was we needed something to make the wheel more grippy.

Re: We need help... A lot of it


A second cable is only needed if your lift plate is too light, or your friction is too heavy, for the lift to lower itself. As I read your posts, your first cable (pull on lift) is also your second cable (pull on lower). If this is correct, you can pretty much ignore the "second cable" posts.

Also, if this is correct (that is, your cable is doubly terminated on the chassis end), you can make your system more repeatable/reliable by adding more wraps to the shaft/axle/spool on the lift side. This basically means making a somewhat longer cable in the shop (add one or two wraps around that spool), including it in your WITHHOLDING ALLOWANCE, then replacing it on the Thursday of your competition.

Re: We need help... A lot of it


Yep. Often for winches, that's a bit larger and drum-shaped.

It's more of a "hold-in-place" on the wheel, giving it more cable to work with (having the same effect as a grippier wheel, theoretically). You'd have a tensioner (turnbuckles work well) elsewhere in the system and run a pretty tight cable for this trick to work, but it should be. Given that you've got a small(ish) wheel width-wise, you might be able to get away with 2 wraps.

I'm going to suggest following the procedure I posted earlier, with the cable not permanently terminated until you get the lift working reliably. It might take extra cable wraps or some grippy material or both, but it should give you some working room.
