pic: Inverted CIM Gearbox V2


Re: pic: Inverted CIM Gearbox V2


hmmm. That looks like a nice gear box compared to some of the others I've seen on here. Where can I find the CAD files? Is there a repository or something for FIRST gearboxes?

Re: pic: Inverted CIM Gearbox V2


I have a grabCAD for pretty much everything I do, but I'm not yet ready to open it just yet for various reasons.

But if you can send me your email address to me via PM, I will be happy to send you the STEP file.

Re: pic: Inverted CIM Gearbox V2


You can make a "Partner Space" in your grabcad project to share with others. That helps keep the secret projects secret, but makes it easy to share what you want.

Re: pic: Inverted CIM Gearbox V2


I see what you did with the low speed :rolleyes:

On to the actual design. It looks like in this design you can actually get rid of the idlers and still have enough room. there seems to be ~1 inch of gap between you bigger dog gear and the body of the CIM. getting rid of that idler gear would be great.
Second, we use FESTO for pneumatics, as they generously give them to us free of charge. So see if you can use a festo piston instead of the one you are currently using.
Overall looks good though. the shifter sticks out of the frame, but it should be well protected by the CIMS around it.

Ill take a closer look at it in person later.

Re: pic: Inverted CIM Gearbox V2


Perhaps in the next version, if I ever do make a third version, I'll change to a FESTO piston. I'm more use to Bimba's pistons because I've been working with them longer. As for the first stage with the idlers, I think if I want to cut out a significant amount of weight, I will look into belts as an option.

EDIT: The reason why I use idlers is because I find that there is really no possible way to not have it without the CIMs touching the gears on the upper shaft between the plates, if you were using gears.

In reply to @asid61: I just played around with the Partner Space in GrabCAD, and I made one, which contains the first and second versions of the inverted gearbox, and unfortunately a large-sized parts folder. The link to it can be found here (I think I'll upload pack-and-go zip files and STEP files later so one doesn't have to have the entire parts folder): https://workbench.grabcad.com/workbe...WAlStxFm6c3ypj

Re: pic: Inverted CIM Gearbox V2


Definitely possible. Using bigger CIM pinions help, AM has 15T and 17T pinions.

Re: pic: Inverted CIM Gearbox V2


I remember that I was making a sketch of a gearbox 1 or 2 weeks ago, using 17T and 84T for the first stage, and it did work.

After plugging in values into JVN, I'm getting 18.91fps for high gear and 7.88fps for low gear. I think the low gear should be around the 6-range if the robot were to last longer in a pushing match. Also, those gears are coming out to be pretty large (there's a 84T, a 50T, and a 70T). At this point, I would consider keeping the weight at a minimum and look for another solution.

What if there was something like a large idler gear (singular) above the 84T gear, and the CIM gears go to that idler gear, and instead of shoulder bolts, I can have that gear be mounted by a hex shaft secured on both sides with some sort of retaining ring?

Re: pic: Inverted CIM Gearbox V2


The front plate following the curves of the cims isn't beneficial. Could take those out and get some more weight savings. Does the output shaft form a live axle in the drive train or is that for sprockets?

Re: pic: Inverted CIM Gearbox V2


I've heard that having the plate curve with the cims helps support them.

Re: pic: Inverted CIM Gearbox V2


The weight you're saving is so marginal (probably less than 0.2 pounds between the two gearboxes) that you might as well shape the plate like that and support the CIMs, even though the gearbox would still be functional without the support. If you need weight that badly, you'd probably be better off lightening all of the gears first.

Re: pic: Inverted CIM Gearbox V2


What about all the gear boxes that run completely cantilevered CIMs?

The OD of the cims isn't super precise anyway, so the plate either takes some iteration, over constrains and deflects the cims, or has a big air gap and would only contact during huge deflections.

Re: pic: Inverted CIM Gearbox V2


Well we are trying to help teach OP that motors don't need that that support and they are designed to be cantilevered.

Furthermore the most time efficient way to loose weight from a design is not making feature you don't need in the first place. Plus this feature is just adding needless time to make the part.
