Charles Doherty 16-01-2016 12:40

Tape Measure Winch

In other First competitions, some robots have used a tape measure winch, to lift or propel itself. Below are some videos that we have looked at. Does anyone have an idea on how to build something like this? Currently, we are considering two wheels feeding the tape out. It would also be helpful if you have pictures or CAD files.

Charles Doherty
Team 5822

Tape Measure Winch
https://www.youtube.com/watch?v=ghuWhsQecFw
https://www.youtube.com/watch?v=jhdRaQZrORM
http://www.chiefdelphi.com/media/img...c3203416_m.jpg
https://www.youtube.com/watch?v=WlSa4RQkxsE
https://www.youtube.com/watch?v=YJn3G7iRkTM

KohKohPuffs 16-01-2016 12:44

Re: Tape Measure Winch

I believe last year 842 used tape measures for their can burglars, so you may want to take a look at that.

Charles Doherty 16-01-2016 13:03

Re: Tape Measure Winch

Thanks KohKoh. Ill look into it.
-Charles Doherty
5822

*Rachelle* 16-01-2016 13:47

Re: Tape Measure Winch

If you guys want to use a tape measure winch, you may want to keep in consideration the rule update (Update 2, page 2) that shows examples of robots climbing and keeping their appendages within 15 in. of their frame perimeter.

hubcappancake 16-01-2016 14:51

Re: Tape Measure Winch

Quote:

Originally Posted by Charles Doherty (Post 1524809)
In other First competitions, some robots have used a tape measure winch, to lift or propel itself. Below are some videos that we have looked at. Does anyone have an idea on how to build something like this? Currently, we are considering two wheels feeding the tape out. It would also be helpful if you have pictures or CAD files.

Charles Doherty
Team 5822

Tape Measure Winch
https://www.youtube.com/watch?v=ghuWhsQecFw
https://www.youtube.com/watch?v=jhdRaQZrORM
http://www.chiefdelphi.com/media/img...c3203416_m.jpg
https://www.youtube.com/watch?v=WlSa4RQkxsE
https://www.youtube.com/watch?v=YJn3G7iRkTM

can you post a close up of your winch

KohKohPuffs 16-01-2016 15:32

Re: Tape Measure Winch

Quote:

Originally Posted by Charles Doherty (Post 1524824)
Thanks KohKoh. Ill look into it.
-Charles Doherty
5822

No problem. However, I realized a tape measure may not work as well due to its structural instability. I believe the way 842 does it is they use a high-grip wheel to reel out the tape measure. That being said, it would be easy to extend the tape measure, but lifting ~150 lbs to the desired height would be a challenge.

If your team has the resources (I don't know because 5822 sounds like a rookie team), then I would strongly suggest to think of some other, more robust solution to the climb. Consider what teams did during 2013 Ultimate Ascent

swwrobotics 16-01-2016 15:58

Re: Tape Measure Winch

Make sure to test the tensile strength of the tape measure with the hook solidly attached. FRC robots can easily weigh 120 lb+ so I'd just be weary of something snapping or breaking. For more strength you could maybe even add a second tape measure facing the opposite way so the tapes don't "fall over" when they're extending. I've never seen a tape measure used for climbing on this scale but I think it'd definitely be cool to see someone go for it :cool:

z_beeblebrox 16-01-2016 16:01

Re: Tape Measure Winch

The tape measure system that us and 842 built last season is documented here.

The requirements are a little different for a climber though...

JohnFogarty 16-01-2016 16:22

Re: Tape Measure Winch

Quote:

Originally Posted by KohKohPuffs (Post 1524916)
No problem. However, I realized a tape measure may not work as well due to its structural instability. I believe the way 842 does it is they use a high-grip wheel to reel out the tape measure. That being said, it would be easy to extend the tape measure, but lifting ~150 lbs to the desired height would be a challenge.

If your team has the resources (I don't know because 5822 sounds like a rookie team), then I would strongly suggest to think of some other, more robust solution to the climb. Consider what teams did during 2013 Ultimate Ascent

Except a rookie team was the first to do it. 3280 was a rookie team in 2010.
3280 did it in 2010 and made it look easy. Granted the method wouldn't be allowed to work the exact same way as you will see in the video the robot flipped end over end which as of update 2 is clarified as illegal.

I still think there are 2 other options for deploying tape measure climbers that won't flip a robot that will employ this simple and effective device. The first and most obvious for most teams to consider is mounting their tape measure climber near the COG of their robot thus potentially keeping the robot level as it ascends.

RyanCahoon 18-01-2016 03:18

Re: Tape Measure Winch

Quote:

Originally Posted by JohnFogarty (Post 1524950)
Except a rookie team was the first to do it. 3280 was a rookie team in 2010.

Actually, not the first.

Vyrotek 18-01-2016 17:07

Re: Tape Measure Winch

Quote:

Originally Posted by *Rachelle* (Post 1524852)
If you guys want to use a tape measure winch, you may want to keep in consideration the rule update (Update 2, page 2) that shows examples of robots climbing and keeping their appendages within 15 in. of their frame perimeter.

Yep. Super important. We almost went down this route. This ruling killed most winch ideas since your bot cannot tip and pull itself up.
