pic: prototype of ramp in up postion


Re: pic: prototype of ramp in up postion


This is an interesting design for a lifting mechanism. Have you considered how you'll stow it inside the robot at the beginning of each match?

What sort of material were you considering for your platform?

I'd love to read more details about how you plan to implement this design.

Re: pic: prototype of ramp in up postion


How long is the ramp, what angle is it at?

Re: pic: prototype of ramp in up postion


Based on the other photo uploaded to CD-Media (http://www.chiefdelphi.com/media/photos/26396?), it appears as if there's no ramp at all. Rather, it's a platform supported by a parallel four-bar linkage. By pulling up upon the top of the linkage with a pneumatic piston, the linkage swings upward and the retracted force of the piston will hold a robot and the platform 12"+ in the air.

This design and ones like it, if they can be made to work properly, are superior to ramps in almost every way, as far as I'm concerned.

Re: pic: prototype of ramp in up postion


how do you expect this to work???

Re: pic: prototype of ramp in up postion


its actually a lift so it would be always parrallel to the ground

it would be folded up so it would be perpedicular to the ground. At the end of the game, a pin would be pulled, it would fall down, a robot would drive on it, and then we'd lift it off the ground to the position in the picture above
the platform would be made out of a honeycomb aluminum
unfortunately, we decided since it would weigh about 20lbs a side that it was a little heavy so we're going with something else

Re: pic: prototype of ramp in up postion


Well, I can tell you this much- there is just enough air in four tanks to eek a little more than 150 lbs fourteen inches. How you link it properly in order to let the air do it's work- a bit of an issue.

Re: pic: prototype of ramp in up postion


exactly :) we designed it to go 13 inches to be sure it would clear the foot mark

Re: pic: prototype of ramp in up postion


We've been looking into honeycomb aluminum for some of the surfaces on our machine as well, but we've not had much luck finding local suppliers. We'd like to take a small sheet and put it through its paces first before committing to its use. We have some concern about how rigid it'll remain over long spans.

20 lbs. per side seems about right, given everything that's involved. It's a fantastic system for teams that really want to focus on scoring bonus points at the end of the match because of the many benefits it has over most ramp designs -- primarily, ease of use by partner robots. I'm interested to see more of what you've decided to use in place of this design.

Re: pic: prototype of ramp in up postion


two years ago, we used honeycomb aluminum for the base and type of honeycomb plastic for the sides, last year, we used honeycomb for to mount electronics on, and both years, it stood up to time.

we also have a 1 inch thick piece about 4*4 inches and people have been jumping on it, throwing it trying to bend since we got it at the beginning of the season and nothing, except for being a little squished in the corners, has happened to it.

we're also thinking of using a new type of honeycomb this year for our frame, but we're arent exactly sure yet

Re: pic: prototype of ramp in up postion


As I was looking at your model, I knoticed that at the position when the ramp is at its max, the piston is pulling dirrectly vertical. When it is in this position, the force from the piston is not able to prevent the ramp from going back down a little ways until the piston has a better pull angle. I think that you would have better luck if the piston was pulling at a slight angle when the ramp is fully up, or you figured out some other way to prevent this from happening.

Re: pic: prototype of ramp in up postion


Ha, we've got out 12" ramps down to 15 pounds for both sides.

Thank god for composites.
