multi-pin connectors
Does anyone here have any idea where I can get something like the connector shown, but for 12 gauge AWG wiring? The biggest I can seem to find is 14 AWG on this page here: http://www.action-electronics.com/molex93.htm
![]() |
Re: multi-pin connectors
The standard Molex connector (like the one pictured) is only made in two sizes. One holds 18-30 AWG and one holds 14-30 AWG. The larger one is also only rated for 15 A.
If you specify what components you are trying to connect somebody may have some suggestions for alternative connectors that might work. |
Re: multi-pin connectors
There is a smaller version of the Anderson battery connectors, they use individual contacts and housings, but can be put in a larger housing to hold 6 contacts (other numbers are available too).
http://www.andersonpower.com/product...powerpole.html |
Re: multi-pin connectors
Wildstang has used the Powerpole connectors for many years. They are available through Terminal Supply and West Mountain Radio. West Mountain also sells a crimp tool that is well worth the money. The shells come in different colors and snap together to form dual and multi core connectors. Our standard for these connectors is that if you are looking at the face of the positive contact, it is on the left side of the connector when assembled.
|
Re: multi-pin connectors
I didn't find the smaller Anderson connectors at TSC, and they hide the big ones under "maintenance", but the radio store does make them easy to buy...
http://www.westmountainradio.com/order_RC.htm |
Re: multi-pin connectors
Mouser has a great selection of molex 93 and other molex sizes.
http://mouser.com/Search/Refine.aspx?Keyword=molex+93 After using lots of different types of molex and anderson powerpole. I would also advise you to stick with anderson powerpole for FIRST. Molex connectors work great, but if you need flip polarity or regroup your wires you will have to rewire your connector which takes significantly longer than anderson power poles. |
Re: multi-pin connectors
Having a wife who's owned a 1970 Dodge for almost 30 years, I'll second the recommendation to not use Molex connectors. Dodge used them for the ignition switch...bad idea! they don't like high current.
|
Re: multi-pin connectors
My apologies... it appears I did not give enough information.
We have two Jaguars on our electronics board. Down under the manipulator area we have two CIM motors that are to driving the wheels. I wanted to run these 4 motors into 4-pin connectors on either end, and plug them together in the middle. So, the 2x red and black wires from the motors would go into, say, a 4-pin male connector. And then the 2x red and black wires from the two Jaguars would go into a 4-pin female connector. Then we'd be able to quickly connect/disconnect them when we want to remove the electronics board. |
Re: multi-pin connectors
I understand what you're trying to do (we're planning the same thing), and I still suggest the Anderson connectors, instead of the Molex connectors.
|
Re: multi-pin connectors
I'll add to the list of folks suggesting the Anderson connectors. The CIM's can pull a fair amount of current and melted Molex connectors aren't much fun.
|
Re: multi-pin connectors
SMC,
These Molex connectors are only rated at about 15 amps as I remember. There just is not enough contact area to handle the high current of the CIM motors, about 129 amps in stall. This current would heat up the contact and melt the nylon block and the wire on both sides of the connector. The Powerpole is a much better alternative and can be configured (in the field) for four pins and a lot more if needed. |
Re: multi-pin connectors
Those Anderson things look HUGE. Aren't they the same thing that we use on the batteries?
Where can I get them for wires as small (compared to the batteries) as 12 gauge AWG? |
Re: multi-pin connectors
Quote:
|
Re: multi-pin connectors
Quote:
|
Re: multi-pin connectors
www.powerwerx.com
45 amp connectors http://www.powerwerx.com/product.asp...017&CtgID=3578 45 amp contacts http://www.powerwerx.com/product.asp?ProdID=1660&CtgID= Crimping tool, it is the most expensive item here, but don't go without it. Distorted contacts don't mate well. http://www.powerwerx.com/product.asp?ProdID=3324&CtgID= If you need the smaller gauge contacts, you can buy connectors with them and salt the smaller gauge contacts away for use when needed. Now, a tip. Don't use the little roll pin when assembling. Put a little (a very small amount) crazy glue on the mating point and slide the plastic housing together. You only get one shot, do it right the first time and slide against a flat surface to get the plastic halves to line up when they stick. Then use the hole where the roll pin would have gone for a small zip tie to keep the connector mated. These connectors can slip apart if you don't. Eugene |
