pic: Team 79 Summer Project Wiring


Re: pic: Team 79 Summer Project Wiring


This is probably the nicest wiring I've ever seen in a render.

Re: pic: Team 79 Summer Project Wiring


How did you do the wiring in Inventor? We have been trying to figure it out and we are having problems.

Thanks,

Mr. Hurlburt
TALON 540 Lead Mentor

Re: pic: Team 79 Summer Project Wiring


On the left go down to create harness (#10), set what you want the name and location to be. Select create segment (#4), click on the first crimp and points to the end point. Right click, finish.

Re: pic: Team 79 Summer Project Wiring


For a little bit more detail Drakan290 made a excellent how to guide

http://www.chiefdelphi.com/forums/sh...ad.php?t=64206

Re: pic: Team 79 Summer Project Wiring


Thanks! I appreciate that. :) I have always wanted to render the actual wiring of the robot in all of our CAD files. We just have the mechanical aspects of it and MAYBE we add a few electrical components. But I figured to try it, and I have the whole summer to perfect it. I'll hopefully finish the whole robot in a week or two. Then i'll shoot for wiring out older robots starting with our 2009 bot CK12.
