Pneumatics Connectors


Hello. I have been given the job of putting together a parts list for all the pneumatics connectors. The only problem is, I am at home, and am not able to see the various connector sizes I would need. I was wondering if anyone would be able to provide a little assistance in figuring out the sizes needed. Any help is appreciated.

Here is a list of the parts I need connectors for. All I need to know is sizes of everything, such as thread size, tube size, etc.

Connectors for:

Storage Tanks
Norgen/Monnier Regulator

And does anyone have a link to a site where I can buy the vibration mounts for the compressor. I just don't know the size of the threads.

Thanks.

Re: Pneumatics Connectors


Here's some links to the the various push-to-connect fittings you'll need:

http://www.chiefdelphi.com/forums/sh...4&postcount=13

The tubing in the KoP is 1/4" OD. Most of the pneumatic components use 1/8" NPT for threaded connections, although some like the accumulators and compressor have 1/4" NPT fittings. The vibration mounts have #8-32 thread, and are basically identical to the ones sold at Vex Robotics.

Re: Pneumatics Connectors


Thank you so much. Big help.

Re: Pneumatics Connectors


we always use smc but there are more out there.

Re: Pneumatics Connectors


Thanks.
