How fast r u gonna go?


Looking at using 2 speed trannys for the first time but I am not sure how fast I can expect to go with 4 cims. Also, how do you determine the running speed of the CIMS so you can figure the correct gear ratios?
Thanks
Bruce

Re: How fast r u gonna go?


About this fast



(If we go 1-speed then a static 11 fps, if we go two speed then a 7 and a 13 or something close)

Re: How fast r u gonna go?


We're looking at 11.5 FPS single speed with 4 CIMs and 2 RS-775s using the CIMulator gearbox.

Re: How fast r u gonna go?


A little off topic but I have never found the benefits of a two speed tranny to out weigh its draw backs.

Pro: Two speed tranny

• High speed
• High Torque
• Having both

Con: Two speed tranny

• Expensive (about $600-700 for 2 on andy mark)
• Added complexity to a robot AKA just one more thing to fail
• Heavy with a asterisk, i know they can be modified to be lighter but still tend to be heavier than single speed trannys

While having the ability to push and go fast is nice it really isn't neccasary. Which is why I think single speed gear boxes are better. You can gear a tough box for a 8:1 or 10:1 gear ratio and do just fine. If for some reason your robot is being pushed around while it has 4 CIMS in its drive train, don't push back, run circles around that bot. Plus your team didn't spend a ton for something you got free in the KOP

Re: How fast r u gonna go?


But, how can you run circles if you run circles around another if they have a shifting gearbox which allows them to out-accelerate you and out-speed you?

Re: How fast r u gonna go?


Funny I just coded a little autonomous maneuver to do just that :)

As far as 2 speeds go, I'm liking the idea for this years game. Not for high torque, but rather the fine tuning when you are capping and grabbing, but high speed when you gunning across the field, or juking that blocking bot.

Right now my juke isn't quite fast enough, I wish I had a 2-speed so I could pump out 15 fps during it.

Re: How fast r u gonna go?


The same way you find out any information about ANY parts in the kit: Look it up.

Go to www.usfirst.org, select FRC, select Game & Season Info, select Competition Manual & Related Docs. On that page, scroll down the the KIT OF PARTS WEBSITE (which Kate spoke about for several minutes during Kickoff - did you watch it?).

On the KoP website, look for "motor curves" in the Parts Data Sheets section.

I'd just give you the URL, but then you wouldn't learn to look for yourself.

Don Don Don


Don Don Don... I have the motor curves and I have the JVN design calculator.
I know the free speed is 5500 rpm. I am not an engineer. I don't know how to figure what I can realistically expect the CIMs to be turning at at nominal load at speed. Sorry, my calculus is nonexistent, I never had physics and I am just trying to help some kids build a robot. Now, if you are willing to help, great.
Bruce

Re: How fast r u gonna go?


Realistically expect them to turn at a speed drawing below 40 amps while cruising, or you're going to have a very dead robot. The data sheets explain 27 amps; use that as a base point.

Re: Don Don Don


If you're geared "reasonably" and your drivetrain doesn't have some ridiculous friction load (or is a Mecanum), the CIMs will run at about 81% of their free speed when at top speed.

Reasonably geared is defined for a drive 4 motors to be "less than 13 fps @ free speed."

-John

Re: How fast r u gonna go?


team 2081 is estimating they're going to go this fast:

http://www.youtube.com/watch?v=SiMHTK15Pik

Re: How fast r u gonna go?


no matter what this year is about speed strength and the exact manipulation of both a two speed transmission is going to put a robot at an advantage if the drivers can handle the speed ive seen the andymark supershifters go too fast for drivers

Re: Don Don Don


Bruce, I find it better to think about how fast the robot SHOULD go than trying to target a specific speed and working out the gear ratio. What is often not mentioned is the fact that all drive motors run through circuit breakers that limit current to 40 amps. If you look at the CIM motor you will see that it's stall current is more like 130 amps. If you stall the motors, you will trip the breakers. If you trip the breakers you are not moving until they reset.

I encourage my team therefore to design the robot so the wheels will slip before the motor current exceeds 40 amps. To do this requires knowledge, or reasonable estimates, of both robot's weight and the coefficient of friction from the wheels.

It will take too long to describe the process in detail here. I have given a presentation on this subject and send it if you PM me with contact information.

The short version (which will likely not help without a background in engineering or physics) is that you need to determine the torque required at the wheel to cause slippage as well as the available torque from the motor at or below 40 amps. The ratio of the two gives you the desired maximum gear ratio. Each stage of gear reduction (gear, sprocket or pulley) could be roughly estimated to reduce the maximum motor speed by roughly 95%. Most gear boxes have 2 stages of gears and then chain to drive the wheels (0.95^3 is about .85). So the speed of the robot SHOULD be something like (motor free speed)*(~0.85 efficiency)*((motor torque at 40 amps)/(wheel torque for slippage))*(wheel circumference). Of course it gets more complicated with multiple motors, multiple wheels and such. Generally safe to assume symmetry and that one or two motors drive half the robot weight for tank or skid steer drive trains.

Now I've probably gone and scared anyone from asking for the 'long' version. :)

As I said, contact me and I can break it down into manageable size bits of information.

Re: How fast r u gonna go?


It is important to remember that humans do need to control the robot and that they can be made to go too fast to control effectively.

However, it is not quite fair to say that AndyMark SuperShifters go to fast as you do have options in the final gear ratio by selecting different sprockets or even different size wheels. There are also software options to limit the top speed should you find your hardware outrunning your drivers.

Re: Don Don Don


John, do you have any information about the test conditions used to establish the 81%? And how much does that vary? (I've always made a similar approximation, but I don't have any hard data to back it up.)
