Post VEX pro 775, broken terminals

VEX pro 775


The connecting terminal of the VEX pro 775 broke while trying to take it off of our robot.
Is there any way to salvage this? Maybe a replacement terminal or soldering the wire to the inside? Or the best way to open it up?

Any lead will be appreciated
Reply With Quote
  #2   Spotlight this post!
Unread 02-28-2018, 05:48 PM
Atikul10152002 Atikul10152002 is offline
Registered User
FRC #6517

Join Date: Feb 2018
Location: United States
Posts: 4
Atikul10152002 is an unknown quantity at this point
Re: VEX pro 775, broken terminals

pardon but the images doesn't seem to show up

Reply With Quote
  #3   Spotlight this post!
Unread 02-28-2018, 05:51 PM
Atikul10152002 Atikul10152002 is offline
Registered User
FRC #6517

Join Date: Feb 2018
Location: United States
Posts: 4
Atikul10152002 is an unknown quantity at this point
Re: VEX pro 775, broken terminals

https://ibb.co/iif1TH
https://ibb.co/jQHRvx
Reply With Quote
  #4   Spotlight this post!
Unread 02-28-2018, 06:06 PM
pkrishna3082's Avatar
pkrishna3082 pkrishna3082 is offline
love/hate relationship with swerve
AKA: Parthiv Krishna
FRC #3082 (Chicken Bot Pie) and FTC #13471 Mentor (Minnetonka)
Team Role: Leadership

Join Date: Mar 2017
Rookie Year: 2016
Location: Minnetonka, MN, USA
Posts: 795
pkrishna3082 has a reputation beyond reputepkrishna3082 has a reputation beyond reputepkrishna3082 has a reputation beyond reputepkrishna3082 has a reputation beyond reputepkrishna3082 has a reputation beyond reputepkrishna3082 has a reputation beyond reputepkrishna3082 has a reputation beyond reputepkrishna3082 has a reputation beyond reputepkrishna3082 has a reputation beyond reputepkrishna3082 has a reputation beyond reputepkrishna3082 has a reputation beyond repute
Re: VEX pro 775, broken terminals

I don't think there's much you can do without running afoul of rule R34.

Quote:
The integral mechanical and electrical system of any motor must not be modified. Motors, servos, and electric solenoids used on the ROBOT shall not be modified in any way, except as follows:
A. The mounting brackets and/or output shaft/interface may be modified to facilitate the physical connection of the motor to the ROBOT and actuated part.
B. The electrical input leads may be trimmed to length as necessary and connectors or splices to additional wiring may be added.
C. The locking pins on the window motors (P/N: 262100-3030 and 262100 3040) may be removed.
D. The connector housings on window, door, windshield wiper or seat motors and Bosch motors (P/N: 6004 RA3 353-01) may be modified to facilitate lead connections.
E. Servos may be modified as specified by the manufacturer (e.g. re programming or modification for continuous rotation).
F. The wiring harness of the Nidec Dynamo BLDC Motor may be modified as documented by FIRST in the "Nidec Dynamo BLDC Motor with Controller" Screensteps article.
Unfortunately it seems like you'll have to write it off. Repairing the motor tab isn't covered under part D.

You could use it on a practice or offseason robot but I wouldn't trust any solder connections to those tabs.
__________________

My posts constitute my opinions, and mine alone, and are not representative of the views held by my team.
2010-2011: FLL 11083, 13873 (Minnetonka Silver) - Programmer
2016-: FRC 3082 (Chicken Bot Pie) - Engineering Captain, fmr. Programming Lead, 2017&2018 Dean's List Finalist
2017-: FTC 13471 (Minnetonka) - Founding Mentor
Reply With Quote
  #5   Spotlight this post!
Unread 03-01-2018, 07:43 AM
Ether's Avatar
Ether Ether is offline
systems engineer (retired)
no team

Join Date: Nov 2009
Rookie Year: 1969
Location: US
Posts: 9,126
Ether has a reputation beyond reputeEther has a reputation beyond reputeEther has a reputation beyond reputeEther has a reputation beyond reputeEther has a reputation beyond reputeEther has a reputation beyond reputeEther has a reputation beyond reputeEther has a reputation beyond reputeEther has a reputation beyond reputeEther has a reputation beyond reputeEther has a reputation beyond repute
Re: VEX pro 775, broken terminals

Quote:
Originally Posted by Atikul10152002 View Post
The connecting terminal of the VEX pro 775 broke while trying to take it off of our robot.
I can just picture in my mind's eye some well-meaning student pulling, twisting, and bending that tab

trying to get the connector off


Reply With Quote
  #6   Spotlight this post!
Unread 03-01-2018, 08:32 AM
Kevin Ray's Avatar
Kevin Ray Kevin Ray is offline
Registered User
None #0329 (Raiders)
Team Role: Mentor

Join Date: Jan 2002
Rookie Year: 2000
Location: Medford, NY
Posts: 238
Kevin Ray is a splendid one to beholdKevin Ray is a splendid one to beholdKevin Ray is a splendid one to beholdKevin Ray is a splendid one to beholdKevin Ray is a splendid one to beholdKevin Ray is a splendid one to beholdKevin Ray is a splendid one to beholdKevin Ray is a splendid one to behold
Re: VEX pro 775, broken terminals

This has been a problem vexing (pun intended) teams since the FIRST build season (...again). In fact earlier this season this question was asked on CD. Unfortunately that motor like the thousands of others across the FIRST community over the years should be displayed on a wall and used for teaching purposes only--that is the only use it can provide your team now. It is one of the first things we teach rookies each year and yet we've had to replace two already this year!! Go figure.
__________________
_____________________________________________

Last words before magic smoke appears: "There, that oughta work!"
Reply With Quote
  #7   Spotlight this post!
Unread 03-01-2018, 08:52 AM
Zac's Avatar
Zac Zac is offline
Registered User
FRC #6328 (Littleton Robotics - Mechanical Advantage)
Team Role: Mentor

Join Date: Jun 2016
Rookie Year: 2009
Location: Massachusetts
Posts: 27
Zac has a brilliant futureZac has a brilliant futureZac has a brilliant futureZac has a brilliant futureZac has a brilliant futureZac has a brilliant futureZac has a brilliant futureZac has a brilliant futureZac has a brilliant futureZac has a brilliant futureZac has a brilliant future
Re: VEX pro 775, broken terminals

Save it as an example of “what can happen”

I also like to keep a few dead ones without tabs around to toss on mechanisms that are “in work” and still being bashed around in assembl steps (which is when lots of tabs get knocked and bent for us). Then when the thing is finally assembled you get a free practice run at swapping the motor out We always design 775 mounts to make the motors easily accessible so this isn’t really a difficult swap.

~Zac
Reply With Quote
  #8   Spotlight this post!
Unread 03-01-2018, 04:20 PM
cbale2000's Avatar
cbale2000 cbale2000 is offline
Registered User
AKA: Chris Bale
FRC #5712 (Gray Matter)
Team Role: Mentor

Join Date: Apr 2006
Rookie Year: 2004
Location: Saginaw, MI
Posts: 1,570
cbale2000 has a reputation beyond reputecbale2000 has a reputation beyond reputecbale2000 has a reputation beyond reputecbale2000 has a reputation beyond reputecbale2000 has a reputation beyond reputecbale2000 has a reputation beyond reputecbale2000 has a reputation beyond reputecbale2000 has a reputation beyond reputecbale2000 has a reputation beyond reputecbale2000 has a reputation beyond reputecbale2000 has a reputation beyond repute
Re: VEX pro 775, broken terminals

Quote:
Originally Posted by Atikul10152002 View Post
It looks like you might have enough length on the terminals to solder them on to one of these:

https://www.therobotspace.com/Produc...ode=trs%2D775C

Now, whether or not that's a good idea is still questionable, I'm not sure I'd use it on a competition robot for fear of the leads coming off, but it would make the motor at least "usable".
__________________
2005-2008: FRC 703 Phoenix - Robot Driver
2009-2016: FRC 703 Phoenix - Mentor
2017-????: FRC 5712 Gray Matter - Mentor
Reply With Quote
  #9   Spotlight this post!
Unread 03-01-2018, 04:34 PM
Zagar's Avatar
Zagar Zagar is offline
1506 Metal Muscle Electrical Mentor
AKA: Greg
FRC #1506 (Metal Muscle)
Team Role: Electrical

Join Date: Feb 2016
Rookie Year: 2015
Location: Manchester, Michigan
Posts: 75
Zagar is a name known to allZagar is a name known to allZagar is a name known to allZagar is a name known to allZagar is a name known to allZagar is a name known to all
Re: VEX pro 775, broken terminals

^ +1

I would say there's plenty there to solder to securely. And if using one of the new boards, you should be fine.
Reply With Quote
  #10   Spotlight this post!
Unread 03-01-2018, 05:08 PM
Atikul10152002 Atikul10152002 is offline
Registered User
FRC #6517

Join Date: Feb 2018
Location: United States
Posts: 4
Atikul10152002 is an unknown quantity at this point
Re: VEX pro 775, broken terminals

Thanks for all the advice, everybody.
Reply With Quote
  #11   Spotlight this post!
Unread 03-02-2018, 07:18 AM
TechWaffle's Avatar
TechWaffle TechWaffle is offline
What did I do this time...
AKA: Brett Gallagher
FRC #0225 (TechFire)
Team Role: Mechanical

Join Date: Oct 2015
Rookie Year: 2016
Location: York, Pennsylvania
Posts: 19
TechWaffle will become famous soon enough
Re: VEX pro 775, broken terminals

That's really terminal-ly bad.

But seriously, you can't fix that under rule R34, as said before.
Reply With Quote
  #12   Spotlight this post!
Unread 03-02-2018, 12:32 PM
asid61's Avatar
asid61 asid61 is online now
Design Simple
AKA: Anand Rajamani
FRC #1072 (Harker Robotics)
Team Role: Mentor

Join Date: Jan 2014
Rookie Year: 2013
Location: Cupertino, CA
Posts: 2,944
asid61 has a reputation beyond reputeasid61 has a reputation beyond reputeasid61 has a reputation beyond reputeasid61 has a reputation beyond reputeasid61 has a reputation beyond reputeasid61 has a reputation beyond reputeasid61 has a reputation beyond reputeasid61 has a reputation beyond reputeasid61 has a reputation beyond reputeasid61 has a reputation beyond reputeasid61 has a reputation beyond repute
Re: VEX pro 775, broken terminals

Quote:
Originally Posted by Zagar View Post
^ +1

I would say there's plenty there to solder to securely. And if using one of the new boards, you should be fine.
Ozzyboards sells a cheaper one as well, with a US distributor now too: http://ozzyboards.com/775-inline-powerpole-connector/
http://ozzyboards.com/775-inline-powerpole-connector-cover/
__________________
Team 1072 2017-present
Team 299 2017
Team 115 2013-2016 (student)

2018 Davis Finalists (w/ 6474 and 3880), 2018 Roebling Winners (w/ 3476, 1323, and 1778)

Reply With Quote
  #13   Spotlight this post!
Unread 03-02-2018, 12:52 PM
cbale2000's Avatar
cbale2000 cbale2000 is offline
Registered User
AKA: Chris Bale
FRC #5712 (Gray Matter)
Team Role: Mentor

Join Date: Apr 2006
Rookie Year: 2004
Location: Saginaw, MI
Posts: 1,570
cbale2000 has a reputation beyond reputecbale2000 has a reputation beyond reputecbale2000 has a reputation beyond reputecbale2000 has a reputation beyond reputecbale2000 has a reputation beyond reputecbale2000 has a reputation beyond reputecbale2000 has a reputation beyond reputecbale2000 has a reputation beyond reputecbale2000 has a reputation beyond reputecbale2000 has a reputation beyond reputecbale2000 has a reputation beyond repute
Re: VEX pro 775, broken terminals

Quote:
Originally Posted by asid61 View Post
Honestly, though I like the robotspace board for our uses, that Ozzyboards connector will probably be an easier fit with the shorter tabs.
__________________
2005-2008: FRC 703 Phoenix - Robot Driver
2009-2016: FRC 703 Phoenix - Mentor
2017-????: FRC 5712 Gray Matter - Mentor
Reply With Quote
  #14   Spotlight this post!
Unread 03-03-2018, 04:53 AM
Ozzy Boards's Avatar
Ozzy Boards Ozzy Boards is offline
Registered User
no team

Join Date: Feb 2018
Location: Australia/US
Posts: 11
Ozzy Boards is a jewel in the roughOzzy Boards is a jewel in the roughOzzy Boards is a jewel in the roughOzzy Boards is a jewel in the rough
Re: VEX pro 775, broken terminals

You should be able to solder 12AWG at a right angle to what remains of the tabs. Running the wire down the side of the motor and using one or two cable ties around the motor case provides very effective stress-relief. I would be careful about using the motor on a competition robot( due to a risk of connection failure) but for a practice robot or prototyping/testing it'll still be fine.

In regards to the TRS-775 Connect, due to the thickness of the supplied spacer( it is around 1/8" or 3mm), it is unlikely to work for this application.

We use a much thinner 1.2mm spacer, which should allow it to work in this application. Additionally due to the reported very-tight fit of the TRS-775, it will probably be difficult to get your bent motor tabs to fit. We did several prototyping runs to ensure the correct fit and thus you shouldn't have an issue doing so with our product.

http://ozzyboards.com/775-inline-powerpole-connector/

Feel free to send me a PM with the height of the tab that is remaining and I can check if it will work
Reply With Quote
  #15   Spotlight this post!
Unread 03-21-2018, 08:30 PM
s3529's Avatar
s3529 s3529 is offline
Registered User
AKA: Stephen
FRC #6352 (LAUNCH TEAM 6352)
Team Role: Coach

Join Date: Jan 2015
Rookie Year: 2011
Location: Peoria, Arizona
Posts: 27
s3529 is an unknown quantity at this point
Re: VEX pro 775, broken terminals

Does anyone know if something like the TETRIX motor power cables used in FTC exists for FRC? Our team broke a tab off of our 500 motor and we're not sure if we can repair or interface with it. Something like a plug that can fit over the motor terminals would be useful, even if it means we lose access to the rear shaft.
