pic: Team 1538's Machined Parts (C)

Jon Jack · #1 20-01-2007, 21:13

loading photo ...

3dfernando · #2 20-01-2007, 21:16

Pretty good parts, are you going to make a 8-wheeled robot?

Billfred · #3 20-01-2007, 21:17

Quote:

Originally Posted by 3dfernando

Pretty good parts, are you going to make a 8-wheeled robot?

I'm betting on six and spares.

Still....did I catch a whiff of West Coast Drive?

Guy Davidson · #4 20-01-2007, 21:30

Looks pretty sweet. Billfred or someone else, could you explain what is West Coast Drive? I'ver heard of the West Coast Offense, but never of the Drive.

Thanks.

Billfred · #5 20-01-2007, 21:32

Quote:

Originally Posted by sumadin

Looks pretty sweet. Billfred or someone else, could you explain what is West Coast Drive? I'ver heard of the West Coast Offense, but never of the Drive.

Thanks.

West Coast Drive, loosely defined, is the small-wheeled, cantilevered setup made famous by 254, 968, 22, 4, 980, and 60 at various points in history.

Ian Curtis · #6 20-01-2007, 21:38

Quote:

Originally Posted by Billfred

West Coast Drive, loosely defined, is the small-wheeled, cantilevered setup made famous by 254, 968, 22, 4, 980, and 60 at various points in history.

And such setups by Rage, Gael Force, and the Rhode Warriors are insignificant?

Actually, I don't know very much on when these things were around, my knowledge of robots (other than very, very good ones) effectively starts in '05. Where such setups pioineered by the teams Billfred mentioned before they were adopted by the East Coast?

Nice parts. Poor lathe operator though, must've taken a while to turn down that hex shaft.

DarkFlame145 · #7 20-01-2007, 21:46

I dont get it, why do teams send parts out to be made. My team makes all of our parts (except what we get in the kit and we buy new wheels). It feels great to learn how to fabricate the parts. My teams ain't that big ether, we have maybe 20 to 25 students from 4 schools and like 8 mentors. Sure we work till the last day till 10pm and pull atleast 2 long Saturdays. But we always have a competitive bot.

Rafi Ahmed · #8 20-01-2007, 21:53

Quote:

Originally Posted by DarkFlame145

I dont get it, why do teams send parts out to be made. My team makes all of our parts (except what we get in the kit and we buy new wheels). It feels great to learn how to fabricate the parts. My teams ain't that big ether, we have maybe 20 to 25 students from 4 schools and like 8 mentors. Sure we work till the last day till 10pm and pull atleast 2 long Saturdays. But we always have a competitive bot.

Some teams do not have facilities to machine their parts and they either have sponsers to machine it for them or pay for them to be machined.

Jon Jack · #9 20-01-2007, 22:18

Billfred, perhaps these parts might be for a variation of the West Coast Drive

(Just wait until we post pictures of our finished robot).

As for DarkFlame145's comment. These parts we made by students at two different shops.

More details to follow...

Travis Covington · #10 20-01-2007, 23:13

Quote:

Originally Posted by jjack

Billfred, perhaps these parts might be for a variation of the West Coast Drive

(Just wait until we post pictures of our finished robot).

More details to follow...

I don't think there is any question about that... Cantilevered wheels, 2 speed dog shifting output shaft powering the center wheels... even the way the pictures are taken are reminiscent of others I have seen.

We're on to you...

DarkFlame145 · #11 21-01-2007, 08:23

Quote:

Originally Posted by raf4far

Some teams do not have facilities to machine their parts and they either have sponsers to machine it for them or pay for them to be machined.

Ah, that makes mroe sense, I guess since the area i live in (red neck USA) Im not use to people not having access to a shop

Quote:

Originally Posted by jjack

As for DarkFlame145's comment. These parts we made by students at two different shops.

Them wheels where great lath work, excuse me from my last comment.

Jon Jack · #12 21-01-2007, 11:39

Quote:

Originally Posted by DarkFlame145

Them wheels where great lath work, excuse me from my last comment.

I believe there were somewhere around 10 lathe operations and 1 CNC operation on a Fadal. Roughly 1.5-2 hours per wheel. Of the 10 lathe operations, 6 were to create the recesses on each side (3 per side), 2 were to true up up both sides (1 per side), 1 to take the diameter down to size and the last was to create the groove where the tread goes. The Fadal operation was used to break some of the edges and then cut out the pattern in the middle.

Karthik · #13 20-01-2007, 23:26

Quote:

Originally Posted by iCurtis

Actually, I don't know very much on when these things were around, my knowledge of robots (other than very, very good ones) effectively starts in '05.

More precisely the setup which is commonly known as the "West Coast Drive" was first seen in 2002, used by Team 60.

This was the four wheeled incarnation of the West Coast Drive.

The 6 wheel version debuted in official competition in the 2004 season, in the twins of Team 60 & 254, as well as Team 22.

Travis Covington · #14 21-01-2007, 00:21

Team 60 had a cantilevered 4 wheel drivetrain in 2001 as well.

Rafi Ahmed · #15 21-01-2007, 00:25

But 60 didn't have the smaller wheels till '02
