Team 1711 prototype

http://www.flickr.com/photos/23220170@N07/

Heres a few images of the robot design we've created. The "jaws" are pneumatically operated and grab the ball loading it to the arm. When the arm is raised the ball is parallel with the over pass and the upper jaw launches it over. We originally were going to use 2 tread wheels and 2 mechanums but then opted for all mechanum. Questions comments or suggestion are appreciated.
  #2   Spotlight this post!
Unread 27-01-2008, 17:10
Jaybee1405

Posts: n/a
Re: Team 1711 prototype

looks awesome!

do you stay within the 80" rule?
  #3   Spotlight this post!
Unread 27-01-2008, 17:24
7-11number1 7-11number1 is offline
ROAR.
FRC #1711 (RAPTORS)

Join Date: Sep 2007
Rookie Year: 2006
Location: Traverse City, Michigan
Posts: 46
7-11number1 will become famous soon enough
Re: Team 1711 prototype

we stretch out to 81 inches when the arm lifts up and is in possession of a ball. Luckily its the third week so we can adjust for that
  #4   Spotlight this post!
Unread 27-01-2008, 17:28
DarkFlame145 DarkFlame145 is offline
That guy
AKA: Dennis
no team (None this season)
Team Role: Alumni

Join Date: Mar 2005
Rookie Year: 2004
Location: Pensacola, FL
Posts: 634
DarkFlame145 has much to be proud ofDarkFlame145 has much to be proud ofDarkFlame145 has much to be proud ofDarkFlame145 has much to be proud ofDarkFlame145 has much to be proud ofDarkFlame145 has much to be proud ofDarkFlame145 has much to be proud ofDarkFlame145 has much to be proud ofDarkFlame145 has much to be proud ofDarkFlame145 has much to be proud of
Send a message via AIM to DarkFlame145
Re: Team 1711 prototype

very impressive
__________________
TR-X 145 of Norwich, NY: Student 2005-2008
Exploding Bacon 1902 of Winter Park, FL: Mentor 2009
US Navy Corpsman 2011-????
  #5   Spotlight this post!
Unread 27-01-2008, 17:32
s_forbes's Avatar
s_forbes s_forbes is offline
anonymous internet person
FRC #0842 (Falcon Robotics)
Team Role: Engineer

Join Date: Jan 2006
Rookie Year: 2006
Location: Phoenix, AZ
Posts: 1,125
s_forbes has a reputation beyond reputes_forbes has a reputation beyond reputes_forbes has a reputation beyond reputes_forbes has a reputation beyond reputes_forbes has a reputation beyond reputes_forbes has a reputation beyond reputes_forbes has a reputation beyond reputes_forbes has a reputation beyond reputes_forbes has a reputation beyond reputes_forbes has a reputation beyond reputes_forbes has a reputation beyond repute
Re: Team 1711 prototype

Very clever design! I'd love to see a movie of it doing it's thing, it looks like it would be very fun to watch.
  #6   Spotlight this post!
Unread 27-01-2008, 17:32
IndySam's Avatar
IndySam IndySam is offline
Registered User
FRC #0829 (Digital Goats)
Team Role: Mentor

Join Date: Nov 2005
Rookie Year: 2004
Location: Indy
Posts: 3,347
IndySam has a reputation beyond reputeIndySam has a reputation beyond reputeIndySam has a reputation beyond reputeIndySam has a reputation beyond reputeIndySam has a reputation beyond reputeIndySam has a reputation beyond reputeIndySam has a reputation beyond reputeIndySam has a reputation beyond reputeIndySam has a reputation beyond reputeIndySam has a reputation beyond reputeIndySam has a reputation beyond repute
Re: Team 1711 prototype

Quote:
Originally Posted by 7-11number1 View Post
we stretch out to 81 inches when the arm lifts up and is in possession of a ball. Luckily its the third week so we can adjust for that
Remember it's not 80" long it's fitting into a 80" circle.


BTW I love the design.
__________________
"Champions are champions not because they do anything extraordinary but because they do the ordinary things better than anyone else." —Chuck Knoll


2015 Indianapolis District Winner
2014 Boilermaker Regional Industrial Design Award
2013 Smoky Mountain Regional Industrial Design Award
2012 Boilermaker Engineering Excellence Award
2010 Boilermaker Rockwell Innovation in Control Award.
2009 Buckeye J&J Gracious Professionalism Award
2009 Boilermaker J&J Gracious Professionalism Award
2008 Boilermaker J&J Gracious Professionalism Award
2007 St Louis Regional Winners
  #7   Spotlight this post!
Unread 27-01-2008, 17:36
esisso esisso is offline
Registered User
AKA: Eitan
FRC #1242 (Team Smiley)
Team Role: Mechanical

Join Date: Jan 2008
Rookie Year: 2004
Location: fort lauderdale
Posts: 40
esisso will become famous soon enough
Send a message via AIM to esisso Send a message via MSN to esisso
Re: Team 1711 prototype

we have a freakishly similar design....may i ask what material you used for the "jaw"....also how do you close it up to fit inside starting position.....congratulations on an amazing looking robot

here is our design (sadly we dont have anyone experienced with CAD) so we use chalk and a board...the design is to scale..we have a protoype, much like yours except with a different method of gripping the ball (we used PVC...i dont personally like the pvc idea i like yours much better)

  #8   Spotlight this post!
Unread 27-01-2008, 17:37
Jaybee1405

Posts: n/a
Re: Team 1711 prototype

Quote:
Originally Posted by IndySam View Post
Remember it's not 80" long it's fitting into a 80" circle.

No it's not. You may not have any two points more than 80" apart (horizontally).
  #9   Spotlight this post!
Unread 27-01-2008, 17:42
MrForbes's Avatar
MrForbes MrForbes is offline
Registered User
AKA: Jim
FRC #1726 (N.E.R.D.S.)
Team Role: Mentor

Join Date: Feb 2006
Rookie Year: 2006
Location: Sierra Vista AZ
Posts: 5,949
MrForbes has a reputation beyond reputeMrForbes has a reputation beyond reputeMrForbes has a reputation beyond reputeMrForbes has a reputation beyond reputeMrForbes has a reputation beyond reputeMrForbes has a reputation beyond reputeMrForbes has a reputation beyond reputeMrForbes has a reputation beyond reputeMrForbes has a reputation beyond reputeMrForbes has a reputation beyond reputeMrForbes has a reputation beyond repute
Re: Team 1711 prototype

That's neat! uses up a lot of air though, doesn't it? we are also dealing with air consumption issues
  #10   Spotlight this post!
Unread 27-01-2008, 17:43
IndySam's Avatar
IndySam IndySam is offline
Registered User
FRC #0829 (Digital Goats)
Team Role: Mentor

Join Date: Nov 2005
Rookie Year: 2004
Location: Indy
Posts: 3,347
IndySam has a reputation beyond reputeIndySam has a reputation beyond reputeIndySam has a reputation beyond reputeIndySam has a reputation beyond reputeIndySam has a reputation beyond reputeIndySam has a reputation beyond reputeIndySam has a reputation beyond reputeIndySam has a reputation beyond reputeIndySam has a reputation beyond reputeIndySam has a reputation beyond reputeIndySam has a reputation beyond repute
Re: Team 1711 prototype

Quote:
Originally Posted by Jaybee1405 View Post
No it's not. You may not have any two points more than 80" apart (horizontally).
<R16> Once the MATCH has started, the ROBOT may assume a PLAYING CONFIGURATION that exceeds the size dimensions specified in Rule <R11>. While in the PLAYING CONFIGURATION, the ROBOT may expand up to a maximum horizontal dimension of 80 inches (e.g. all parts of the ROBOT must fit within an imaginary 80-inch-diameter upright cylinder).

Read this http://www.chiefdelphi.com/forums/sh...&highlight=r16
__________________
"Champions are champions not because they do anything extraordinary but because they do the ordinary things better than anyone else." —Chuck Knoll


2015 Indianapolis District Winner
2014 Boilermaker Regional Industrial Design Award
2013 Smoky Mountain Regional Industrial Design Award
2012 Boilermaker Engineering Excellence Award
2010 Boilermaker Rockwell Innovation in Control Award.
2009 Buckeye J&J Gracious Professionalism Award
2009 Boilermaker J&J Gracious Professionalism Award
2008 Boilermaker J&J Gracious Professionalism Award
2007 St Louis Regional Winners
  #11   Spotlight this post!
Unread 27-01-2008, 17:45
MrForbes's Avatar
MrForbes MrForbes is offline
Registered User
AKA: Jim
FRC #1726 (N.E.R.D.S.)
Team Role: Mentor

Join Date: Feb 2006
Rookie Year: 2006
Location: Sierra Vista AZ
Posts: 5,949
MrForbes has a reputation beyond reputeMrForbes has a reputation beyond reputeMrForbes has a reputation beyond reputeMrForbes has a reputation beyond reputeMrForbes has a reputation beyond reputeMrForbes has a reputation beyond reputeMrForbes has a reputation beyond reputeMrForbes has a reputation beyond reputeMrForbes has a reputation beyond reputeMrForbes has a reputation beyond reputeMrForbes has a reputation beyond repute
Re: Team 1711 prototype

We've been thru the 80" rule discussion in a few different threads...and the Q&A addresses it also....the circle thing is an example, but the rule says only that you can't have two points further apart than 80" in a horizontal direction.

Measuring this can be a bit difficult.
  #12   Spotlight this post!
Unread 27-01-2008, 17:47
esisso esisso is offline
Registered User
AKA: Eitan
FRC #1242 (Team Smiley)
Team Role: Mechanical

Join Date: Jan 2008
Rookie Year: 2004
Location: fort lauderdale
Posts: 40
esisso will become famous soon enough
Send a message via AIM to esisso Send a message via MSN to esisso
Re: Team 1711 prototype

oh and can i reccomend you use the same tread that u used for the traction wheels as ball "grippers" they grab the ball like no other
  #13   Spotlight this post!
Unread 27-01-2008, 17:48
Jaybee1405

Posts: n/a
Re: Team 1711 prototype

Quote:
Originally Posted by IndySam View Post
<R16> Once the MATCH has started, the ROBOT may assume a PLAYING CONFIGURATION that exceeds the size dimensions specified in Rule <R11>. While in the PLAYING CONFIGURATION, the ROBOT may expand up to a maximum horizontal dimension of 80 inches (e.g. all parts of the ROBOT must fit within an imaginary 80-inch-diameter upright cylinder).

Read this http://www.chiefdelphi.com/forums/sh...&highlight=r16
I was told by an official FIRST regional inspector that it is not an upright cylinder. The shape is more like a very high piece of pie (ex. take an 80" long piece of extrusion and make a sweep from the farthest point.

Thank you Squirrel.
  #14   Spotlight this post!
Unread 27-01-2008, 18:54
7-11number1 7-11number1 is offline
ROAR.
FRC #1711 (RAPTORS)

Join Date: Sep 2007
Rookie Year: 2006
Location: Traverse City, Michigan
Posts: 46
7-11number1 will become famous soon enough
Re: Team 1711 prototype

Quote:
Originally Posted by esisso View Post
we have a freakishly similar design....may i ask what material you used for the "jaw"....also how do you close it up to fit inside starting position.....congratulations on an amazing looking robot

here is our design (sadly we dont have anyone experienced with CAD) so we use chalk and a board...the design is to scale..we have a protoype, much like yours except with a different method of gripping the ball (we used PVC...i dont personally like the pvc idea i like yours much better)

The Jaws are made from some AL pipes one of our mentors shop had lying around. As to fit in the starting dimensions the Jaws fold up against the arm almost vertically. Its just barely under height restriction and the 80in rule is a little touchy for us. Were gonna have to bend or shorten the jaws slightly
  #15   Spotlight this post!
Unread 27-01-2008, 21:06
7-11number1 7-11number1 is offline
ROAR.
FRC #1711 (RAPTORS)

Join Date: Sep 2007
Rookie Year: 2006
Location: Traverse City, Michigan
Posts: 46
7-11number1 will become famous soon enough
Re: Team 1711 prototype

Quote:
Originally Posted by esisso View Post
we have a freakishly similar design....may i ask what material you used for the "jaw"....also how do you close it up to fit inside starting position.....congratulations on an amazing looking robot
We used 1" electrical conduit and a pipe bender. Also, if you use conduit, DO NOT DRILL THROUGH IT or flatten it. Use pipe clams to avoid creating potential failure points. Note: Last year at the Michigan regional a team constructed an arm out of PVC and it snapped.
