gyroscope problems

I am having problems figuring out how the gyroscope connects to the rest of the system. If anyone has any links to manuals and documents about this, or has information that they can type out, please post.
  #2   Spotlight this post!
Unread 20-01-2010, 18:57
WGRAY WGRAY is offline
Registered User
FRC #2027

Join Date: Jan 2007
Location: westbury
Posts: 22
WGRAY is an unknown quantity at this point
Re: gyroscope problems

In Labview , go to examples, you should see the gyro example, open it and then open the gyro example vi. the front panel has a wiring diagram for the gyro.
  #3   Spotlight this post!
Unread 20-01-2010, 19:00
Phoenix Spud's Avatar
Phoenix Spud Phoenix Spud is offline
Everyone. Everywhere.
FRC #3132 (Thunder Down Under)
Team Role: College Student

Join Date: Jan 2009
Rookie Year: 2004
Location: Sydney, Australia
Posts: 702
Phoenix Spud has a reputation beyond reputePhoenix Spud has a reputation beyond reputePhoenix Spud has a reputation beyond reputePhoenix Spud has a reputation beyond reputePhoenix Spud has a reputation beyond reputePhoenix Spud has a reputation beyond reputePhoenix Spud has a reputation beyond reputePhoenix Spud has a reputation beyond reputePhoenix Spud has a reputation beyond reputePhoenix Spud has a reputation beyond reputePhoenix Spud has a reputation beyond repute
Re: gyroscope problems

Have you tried the 2010 FIRST sensor manual? You can find it on this page, just scroll down to section 8 and you should see it.

Hope that helps!
__________________
Sarah Heimlich
Outreach Mentor | Business Mentor
FIRST® TEAM 3132
  #4   Spotlight this post!
Unread 20-01-2010, 23:17
PortugazD.Ace's Avatar
PortugazD.Ace PortugazD.Ace is offline
Registered User
AKA: Timothy Gonzales
FRC #1165 (Team Paradise)
Team Role: Student

Join Date: Jan 2010
Rookie Year: 2008
Location: Arizona
Posts: 46
PortugazD.Ace is an unknown quantity at this point
Re: gyroscope problems

I looked in the sensor manual and it only had technical information. BTW, I don't have LabView installed.
  #5   Spotlight this post!
Unread 23-01-2010, 10:31
Pausert Pausert is offline
Registered User
FRC #1727 (REX)
Team Role: Leadership

Join Date: Jan 2009
Rookie Year: 2007
Location: Maryland
Posts: 69
Pausert is an unknown quantity at this point
Re: gyroscope problems

What language are you planning to program in?
  #6   Spotlight this post!
Unread 23-01-2010, 11:55
PortugazD.Ace's Avatar
PortugazD.Ace PortugazD.Ace is offline
Registered User
AKA: Timothy Gonzales
FRC #1165 (Team Paradise)
Team Role: Student

Join Date: Jan 2010
Rookie Year: 2008
Location: Arizona
Posts: 46
PortugazD.Ace is an unknown quantity at this point
Re: gyroscope problems

Most likely LabView, but it's not installed on my personal computer.
  #7   Spotlight this post!
Unread 23-01-2010, 17:35
apalrd's Avatar
apalrd apalrd is offline
More Torque!
AKA: Andrew Palardy (Most people call me Palardy)
VRC #3333
Team Role: College Student

Join Date: Mar 2009
Rookie Year: 2009
Location: Auburn Hills, MI
Posts: 1,347
apalrd has a reputation beyond reputeapalrd has a reputation beyond reputeapalrd has a reputation beyond reputeapalrd has a reputation beyond reputeapalrd has a reputation beyond reputeapalrd has a reputation beyond reputeapalrd has a reputation beyond reputeapalrd has a reputation beyond reputeapalrd has a reputation beyond reputeapalrd has a reputation beyond reputeapalrd has a reputation beyond repute
Re: gyroscope problems

You should install it on every computer you could use to program. It takes a few hours, so installing it will take a long time.

The sensor should have a +5, GND, and signal/output pins. Take a PWM cable (3 pins), and cut off the end with the female connector that is long enough to connect from the gyro mounting point to the cRio analog board plus a little extra. Strip the three wires, connect the black to GND, red to +5, and white to SIG.

We generally put our gyros in a small project box and attach them to the robot with velcro.

As for software, the only thing you need to know is the volts per degree per second of the gyro, which can be calculated. I would guess that the sensor manual might tell you that, but I didn't read the sensor manual so I don't know for sure. If the gyro goes backwards, then make the gain negative.
