Hello,
My team has weight issues and I came up with the (albeit stupid) idea to use balloons with Helium to help the weight a little bit. Would it be legal in the first place?
Thank you.
7 Likes
Think about how much air fits inside your allowable robot volume that has a maximum height of 45 inches. Now calculate how much that air weighs. Your helium filled device would be able to lift slightly less than that.
Drill a few holes instead.
4 Likes
If your robot was at maximum volume and consisted entirely of Helium somehow held together with a massless balloon, it would have a buoyancy of just over one pound.
9 Likes
Did you run the math first? You need a balloon about 3 feet in diameter to lift 1 pound. Is that practical?
1 Like
DO IT. You got this, fam.
Remember, once the match begins, you can gain another 12" in every horizontal directions. So that’s a bunch more unaccounted volume you can use.
22 Likes
Assuming your robot is a circle (for the highest volume and lowest perimeter) and you find a way to fit all of the balloons into your frame perimeter, you will have about 51,500 in^3 (about 30 cubic feet) for the balloons, and 136,700 in^3 for the balloons after you extend 12 inches in every direction (about 80 cubic feet). Every cubic foot of helium can lift about 0.069 pounds, so you can lift about 2 pounds while staying in frame perimeter or about 5 pounds while extending out. Unless your robot has no components and you can find a way to fit all of your balloons in your frame perimeter at the beginning, you might need to find another way to solve your weight problem.
1 Like
it’s probably not legal if your helium balloons hold any pressure and aren’t pressure rated.
5 Likes
We find that the Java function Levitate.robot works just as well. The only problem is that you have to weigh with the battery and hope the RI doesn’t realize the robot is on.
12 Likes
Have you considered using the SLIM CIM? It’s a powerful alternative to the CIM and weighs a lot less. Anyone using a Slim CIM?
/s
12 Likes
A few “reasonable” alternates:
- Negative Mass is a thing, though as far as I can tell only in theories. Find a way to make it more experimental, and Bob’s your uncle.
- Suspend a large mass of osmium directly overhead of the inspection station. The large amount of mass will alter earth’s gravitational field to reduce the apparent weight measured at the scale. [^1][^2]
- Build the robot from steel, then suspend a very large magnet over the inspection station. [^3]
[^1] Physics Exercise: Determine the radius of an osmium sphere required to reduce measured robot weight by one pound. Assume sphere is suspended such that the lower extreme of it is 500 ft above the inspection station.
[^2] Psychology Exercise: How do you convince onlookers that such a sphere is “OK” and there is “no reason” to panic?
[^3] Physics Exercise: Using an electromagnet model of your choice, determine a solution for the geometry of an electromagnet positioned 500ft above the inspection station, that is powered by an existing nuclear generator of your choice, and reduces the apparent robot weight by 1 pound.
11 Likes
It’s probably easier to switch to competing at an event with higher elevation or closer to the equator, taking advantage of the fact that the limit is on weight, not mass, and that the Earth’s gravity isn’t the same everywhere.
8 Likes
3 Likes
That’s not an issue if they can’t see it. All you need is a couple of projectors and hope nobody looks too close.
1 Like
Helium… Nope for reasons stated.
In all seriousness, you are not the first team to go over weight late in build season. If you explain the general design of your robot, or better yet provide a picture, and tell us how far over you are we can make much better suggestions on where to go looking for weight savings.
This was a constant battle on my last team. I think we ended up over 4 years in a row. Current team has only managed to go over once in the last 5 years.
Unfortunately drilling holes is likely one of the lowest effort vs return options. You don’t get much weight savings, it is hard to do on an assembled robot and you need to do lots of stress calcs to determine how much you can remove, and where. Removing metal after the fact is much harder than designing in “skeleton style” structural members.
Taking a hard look at your motor choices, and replacing CIMs with MiniCIMs is often an easy way to reduce weight. Drastically reducing lexan thickness for covers, and belly pans is another. Nuclear option is sacrificing mechanisms to the build gods.
1 Like
I have heard a legend about an air vent over the scale at an event causing robots to vary by a pound or two depending on whether is was on or off. Hypothetically if your robot has a flat surface to catch the air, then weighing it surrounded by fans blowing up could make it lighter.
When I was in wrestling in high school I found if I raised my arms at the right time I could make the scale register two pounds lighter than if I didn’t. Maybe one of your mechanisms is spring loaded and could be set up to move at the right time during weighing.
Helium balloons, like pneumatic tires or gas springs, are not considered pneumatic devices and could be used legally. Previous posts have stated the obvious volume constraints. As you point out, they are not pressure rated, so they could not be hooked up to the robot’s pneumatic system as a pneumatic device would be.
Good luck with that! weigh-in is not a snapshot, we wait for the scale to reach a steady state reading.
3 Likes
Slide over and change the scale to KG when they are not looking.
8 Likes
If you were able to remove all of the air from your robot and have a perfect vacuum(in lieu of helium), I believe you could lose up to 3.3lbs. The good news is you probably have a lot of air in your robot, so there is a good chance you can lose a few lbs there!
2 Likes
In the context of the rest of this thread, here’s where my thoughts went:
Editorial: @gerthworm does not condone drugs, physical violence, or any related tomfoolery against robot inspectors.
5 Likes
It would require an osmium sphere with a radius of approximately 12,600 meters. All things said, reducing your weight with helium is a far more viable solution than the giant osmium sphere.
Work:
Assuming a 126 lb robot and newtonian gravity, and that the density of osmium is 22,590 \frac{kg}{m^3} .
Quick googling reveals that the robot has a mass of 57.1526 kg and the required force to support one pound of mass is 4.45 newtons, the distance from the bottom edge is 152.4m. Gravitational force is given by the equation F_G=\frac{Gm_1m_2}{r^2} where r is the distance between the objects’ center of mass, m_1 and m_2 are the objects’ masses, and G is the universal constant of gravitation. Since the osmium is a sphere, the distance between the centers of mass is l+r, and the mass of the sphere is \frac{4\rho\pi r^3}{3} where \rho is the density, r is the radius of the sphere, and l is the distance between the robot’s center of mass and the bottom edge of the sphere. Substituting those into the force of gravity equation I got this:
F_G=\frac{4\rho\pi G m_1 r^3}{3(l+r)^2}.
To solve for r I substituted \frac{4\rho\pi m_1}{3} for a since all are constants to get this:
F_G = \frac{ar^3}{(l+r)^2}
I used synthetic division to break dow the fraction:
F_G=ar-2la+\frac{3l^2 a}{l+r}-\frac{4l^3 a}{(l+r)^2}
I assumed the third and fourth terms had a negligible effect so I could actually solve for r:
F_G = ar-2la
Solved for r:
r=\frac{F_G}{a}+2l
substituted values constants back in for a:
r=\frac{3F_G}{4\rho\pi G m_1}
Throw in numbers:
r = \frac{3*4.45N}{4*22500\frac {kg}{m^3}*\pi*57.1526 kg*6.67*10^{-11}\frac{m^3}{kgs^2}}+2(152.4m)=12641.3392442m=12600m
I did plug my answer back into my original equation and got 4.45195673709N for force, which is accurate to the same number of significant digits I put in.
